Delta®
Stem Assembly - 2H
Model#: RP1740
Stem Assembly - 2H
Stem Assembly - 2H
Delta®
Stem Assembly - 2H
Model#: RP1740

Finish:Not Applicable

List Price: $16.05
Availability: In stock
PRODUCT FEATURES
  • Use with 2-handle kitchen or bathroom faucets
  • Made from durable plastic for lasting use and reliability
  • Designed for use in both hot and cold valves
SUPPORT
Installation Information
Connection Type :
NA
REVIEWS
Rated 5 out of 5 by from Hope for the hopeless Didn't think my odd, old tub faucet was repairable (one handle for temp, one for water flow) but this part and a few others and about an hour of time and it's working like new. Thanks for having diagrams and parts in stock!
Date published: 2020-11-20
Rated 5 out of 5 by from Works Great Installation was easy, part certainly appears to be high quality, and it has worked perfectly.
Date published: 2019-10-18
Rated 5 out of 5 by from stem replacement good replacement, the leak stopped.
Date published: 2017-12-07
Rated 5 out of 5 by from Faucet drip Since I installed the new faucet items I purchased from you the drip has been fixed.
Date published: 2017-01-06
Rated 5 out of 5 by from A perfect replacement I could not find the needed parts locally, so found faucet direct on the internet. Parts were a perfect fit and replacement, service was fast and excellent ( and affordable).
Date published: 2016-02-26
Rated 5 out of 5 by from The right parts for the job! After trying so called "equivalent" replacement parts from a "big box" home improvement center and from a local hardware store (and having them leak) it was great to get true manufacturer's parts. They fit . . . and they WORK!
Date published: 2012-06-05
Rated 5 out of 5 by from easy Easy to find, easy to get, easy to install!!!!
Date published: 2010-05-09
  • y_2021, m_1, d_21, h_17
  • bvseo_bulk, prod_bvrr, vn_bulk_3.0.13
  • cp_1, bvpage1
  • co_hasreviews, tv_0, tr_7
  • loc_en_US, sid_RP1740, prod, sort_[SortEntry(order=SUBMISSION_TIME, direction=DESCENDING)]
  • clientName_deltafaucet
  • bvseo_sdk, dw_cartridge, 18.2.0, p_sdk_3.2.0
  • CLOUD, getReviews, 6ms
  • reviews, product
Q&A

Is there a 1 inch stem extension for this product?

I need to extend the stem approx. 1 inch and have been unable to find any extension around this range. Does one exist?
Asked by: Max22
Hi Max22, Thank you for your question. Unfortunately, we do not have an extension for this stem unit. Thanks, Jon
Answered by: DeltaFaucet3
Date published: 2015-10-22

I called to order a replacement RP1740. The person said my Neo style two handle 2467 faucet is discontinued, and is sending an RP70676 stem to replace the RP1740. Is this the correct replacement?

Asked by: turfdr
Thank you for your question, turfdr! The part number RP70676 can be used as a substitute for the standard RP25513 or RP24096 stem unit assemblies. This part number; however, includes the 1/4 turn stop, seat and spring as well as a bonnet nut. Best regards, Edward
Answered by: Delta Faucet
Date published: 2020-03-07

How is this and RP41701 different? Are they interchangeable?

Asked by: bcsmith
Hi, bcsmith! Thank you for your question. The Delta RP1740 and RP41701 are not interchangeable as they are different sizes and fit different faucets. Best Regards, Rosanna
Answered by: Delta Faucet
Date published: 2019-02-13

How do I remove the handle on my rp1740?

Asked by: Bill
Thank you for your question. Without knowing which handle you have, it is difficult to advise you on how to remove it. Some of our handles are held on with a set screw on the side of the handle, and some have a screw in the top of the handle underneath the button.
Answered by: Delta1
Date published: 2013-10-22

Is there an instruction sheet for replacing Stem RP1740?

Asked by: Chickadee
Chickadee, Thank you for your question. The instructions for replacing the stem unit will be in the Installation Instructions for your specific model. Please click the link below to view our How-To Video for help removing the stem unit. Once the water supplies are turned off, you can skip to minute 1:57. https://www.deltafaucet.com/video-gallery/video-page?videoId=wWM-HK3si5k Regards, Jon
Answered by: DeltaFaucet3
Date published: 2019-08-18

RP1740 vs RP25513

Both look like same except brass and plastic. Our bathroom faucet have brass stem cartridge with two handle centerset type. Can RP1740 cartridge be used in place of the RP25513? Thanks in advance.
Asked by: W
Hi, W! Thank you for your question. The RP1740 are plastic and they are meant for faucets that have knob handles like the clear, acrylic, crystal-looking handles. The RP25513 are brass and they are meant for faucets that have metal-lever handles. Best Regards, Rosanna
Answered by: Rosanna
Date published: 2018-08-17

Internal O-Ring in RP1740 stem unit

Hello Delta, Can you please give me the part # and the size of the internal O-Ring for the RP1740 stem unit? Thanks, Ken
Asked by: Ken
I have used the Danco #83 OD 1/2” ID 3/8” thickness 3/32”. Not a perfect fit but it will stop leaks
Answered by: Joker48
Date published: 2020-10-29

are the o-rings for the rp1740 available seperate or do you have to buy the stem each time?

Asked by: gmac55
Hi, gmac55! Thank you for your question. We do recommend to replace the whole stem unit assembly instead of just the o-ring for the Delta RP1740 Stem Unit Assembly. Best Regards, Rosanna
Answered by: Delta Faucet
Date published: 2020-05-29
