Delta®

Cartridge Assembly - MultiChoice® Universal - 17 Series

Model#: RP46463
Add to Favorites
Find local Delta® installers.
Delta®
Cartridge Assembly - MultiChoice® Universal - 17 Series
Model#: RP46463
List Price: $154.00
Online Price: $123.20
Free Ground Shipping All Orders $49+
Add to Favorites
Find local Delta® installers.
PRODUCT FEATURES
Dual-function valve cartridge maintains a consistent water temperature from one shower to the next. Monitors water pressure to balance temperature. All Delta tub and shower faucets are engineered to keep the water temperature within a safe ±3.6° F (±1.7° C)*. This technology makes sure your family doesn’t experience a sudden and possibly unsafe change in water temperature as a result of running water elsewhere, such as using a dishwasher, flushing a toilet or running a washing machine. The valve cartridge features an adjustable handle limit stop that, when properly set, helps ensure the handle cannot be turned to a position that is too hot for comfort*. Easily replaced seals make maintenance a snap. This cartridge is included with tub and shower trim packages. *Requires inlet water temperature be set correctly. May require seasonal adjustments.
  • Monitor® dual-function pressure balance cartridge
  • Use with MultiChoice® 1300/1400 Series tub & showers produced after March 2006
  • Allows for separate volume and temperature control
  • ASSE certified (ASSE 1016)
Documents & Specs
Installation Information
Overall Height (in.) :
8
Valve Type:
NA
REVIEWS
Rated 3 out of 5 by from Wasn't what I needed I bought this based off of what the person told me I needed- I needed a whole different part. Now I have to figure out how to return it, if i even can.
Date published: 2026-04-24
Rated 1 out of 5 by from Recommended Cartridge for fixture did not work The cartridge stop allowed my valve handle to over-travel going beyond the shutoff point which allowed for small stream when the handle was fully closed.
Date published: 2026-03-13
Rated 1 out of 5 by from Unfortunately leaks when valve closed Just installed this 2 months ago & experienced the same constant drip issue with Trinsic rain can. Can you please contact me & offer a solution?
Date published: 2026-01-30
Rated 1 out of 5 by from Destroys itself by being used. I have major complaints about the Delta 17 series cartridge RP46463. Absolutely one of the worst plumbing products I have ever used. If the contractors installed any other cartridge I would never had to order so many replacement parts. Screws back out constantly, allowing the assembly to fall apart and destroy the teeth. I have replaced 2 of these in less than a year of their installation. Horrible product.
Date published: 2025-12-12
Rated 1 out of 5 by from Replaced 3x in 7 years! I have had to replace this valve now three times since it was originally installed 7 years ago because it is randomly drips/releases water. My water bill has skyrocketed, which led to me putting a bucket under the faucet in the tub only to see that it was filling up! Also, it is very difficult to get it to allow hot enough water for a bath -- it is fine for showers but for a bath I want hotter water. It is nearly impossible to get the setting to allow hotter water (and, no, it is not a problem with my water heater).
Date published: 2025-05-14
Rated 1 out of 5 by from I looked at the party supposed to be in the 1700 series why I needed a 1700 series but it was 1717 series so I didn’t understand what was the difference until I got the product so I was upset It was the wrong part so I don’t know what to do with it
Date published: 2025-03-25
Rated 1 out of 5 by from Dripping rain head. Less then a year old on a new shower and a constant drip. Nothing but a headache.
Date published: 2024-11-17
Rated 1 out of 5 by from NOT Universal - beware!!!! This replacement valve is NOT a Universal fit as is stated. I just spent $100 for nothing! I will be contacting the company. If you have a 17 or 1700 series shower and it is leaking, chances are you just need to replace the seat springs and seals. This cartridge does not fit because it has two triangular notches on either side that should fit flat into the shower receptacle stem, but mine has a one sided square notch, which means this one cannot seat properly in the stem. My shower is circa 2004??? Not happy.
Date published: 2024-11-17
  • y_2026, m_6, d_16, h_13
  • bvseo_bulk, prod_bvrr, vn_bulk_3.0.46
  • cp_1, bvpage1
  • co_hasreviews, tv_0, tr_46
  • loc_en_US, sid_RP46463, prod, sort_[SortEntry(order=SUBMISSION_TIME, direction=DESCENDING)]
  • clientName_deltafaucet
  • bvseo_sdk, dw_cartridge, 18.2.0, p_sdk_3.2.0
  • CLOUD, getReviews, 7ms
  • reviews, product
Q&A

Is the cartridge RP46463 interchangeable with other delta cartridges?

Asked by: Kyle
Hello Kyle, Thank you for your question. We are happy to help! If a different cartridge is used in the MultiChoice valve, the handle and trim kit would also need to be changed. The Delta RP46463 cartridge would be used in a 17 series faucet trim. Other cartridge part numbers would not work with a 17 series trim kit. You can replace the 17 series trim and cartridge with a 13/14 series (includes RP46074 cartridge) or 17T series (includes RP47201 cartridge) trim without changing the MultiChoice valve rough. Best regards, Bryan
Answered by: Delta Faucet
Date published: 2024-03-28

I don’t know if the rough valve is pre-2005 so not sure which cartridge to use. Is there a date stamped on the host valve? Thanks! It’s a series 1700

Asked by: Deepcdvr
Hello Deepcdvr! Thank you for your question. I am happy to help. There would not be a date stamped on the valve. The easiest way to determine the correct cartridge to use is by looking at the color of the cap on the cartridge. If the cap is white you would use RP32104 (pre-2005). If it is grey you would use rp46463 (post 2005). Best Regards, Antoine
Answered by: Delta7
Date published: 2021-01-02

I think my shower cartridge is a series 17, it looks very similar but mine is made out of white plastic instead of grey. How can I make sure I buy the right model? I could send you a picture.

Asked by: Rainman

Does the replacement cartridge RP46463 fit all models for series 17/17T MultiChoice? And how long should these last?

Asked by: Marc

How can I clear trash from this RP 46463 valve?

Asked by: Big JIM
Hi Big JIM, Thank you for your question about the Delta Faucet RP46463. You can remove the cartridge, clean any trapped debris that is on the bottom of the cartridge, and clean the removable adapter behind the cartridge. Or the adapter can be replaced with RP46073 if the rubber parts are worn or damaged. Please reach out with any additional questions! Best Regards, Bryan Digital Communications Specialist
Answered by: Customer Service
Date published: 2024-01-31

Is this covered under warranty?

Asked by: SAMMIE
Hi SAMMIE, Thank you for your question about the Delta Faucet RP46463 MultiChoice® 17 Series Cartridge Assembly. I am sorry this information was not readily available, and I am happy to help! All Delta Faucet products and parts purchased from authorized sellers are guaranteed to be free of defects in material and workmanship by the Lifetime Limited Warranty. https://www.deltafaucet.com/warranty Please contact us directly if you have any questions or need additional assistance. We appreciate your business and look forward to continuing to serve you! Best Regards, Bryan Digital Communications Specialist
Answered by: Customer Service
Date published: 2024-03-28

My Delta shower only single handle valve is dripping from the shower head, my cartridge is dark grey. Will the 17 universal cartridge work as a replacement? I purchased the shower valve in 2014.

Asked by: Mickey
Hi Mickey, Thanks so much for contacting Delta Faucet Company about RP46463! Our post 2006 shower cartridge in dark gray is either for a T13/14 or T17 series. I would verify if the single handle controls volume and temperature, then it's a T13/14 which would need the RP46074. If the handle has a temperature control in addition to the volume control handle, then it's a T17 and the RP46463 would be correct. Please contact us directly if you have any questions or need additional assistance. Best Regards, Nicole Digital Communications Specialist
Answered by: Customer Service
Date published: 2023-07-19

Does it work with cartridge delta RP32104?

Asked by: farah
Hi Farah, Thank you so much for contacting Delta Faucet Company! The Delta RP46463 cannot be used in place of the Delta RP32104. Please reach out with further questions! Best Regards, Skyler Digital Communications Specialist
Answered by: Customer Service
Date published: 2024-03-28

I have a shower head that uses the RP46463 cartridge assembly. The shower head will not stop dripping. Is there a gasket I can replace to stop the drip ?

Asked by: Matt
Hi Matt! Thank you for your question and we are happy to help. The Delta RR4993 seats and springs may be replaced in the RP46463 to stop dripping. With any further questions or concerns, please do not hesitate to reach out to us again. Best Regards, Carrie
Answered by: Customer Service
Date published: 2024-03-28

Is this cartridge assembly ( RP46463) for Delta shower faucet T17038? Purchased 2014.

Asked by: Specs
Hello Customer! Thank you for your question and we are happy to help. The Delta RP46463 is the correct cartridge for the Delta T17038. With any further questions or concerns, please do not hesitate to reach out to us again. Best Regards, Carrie
Answered by: Customer Service
Date published: 2024-02-27

Does the RP46463 valve work with the Dryden T17T251-PN-WE shower faucet?

Asked by: Debbie
Hello, Thank you for your question! No, model T17T251-PN-WE uses the RP47201 cartridge. https://www.deltafaucet.com/parts/product/RP47201.html Please reach out with further questions! Best Regards, Tim Digital Communications Specialist
Answered by: Customer Service
Date published: 2024-11-19

Will this cartridge replacement fix a slow drip when turned off or are there other gaskets that need to be replaced as well? thanks

Asked by: Edzim
Hi Edzim, Thank you for your question about the Delta Faucet RP46463. If a 17 series MultiChoice faucet is dripping while off, we recommend replacing the RP46073 adapter included with this cartridge. The rubber parts can wear or be damaged over time. https://www.deltafaucet.com/parts/product/RP46073.html Please reach out if you have any additional questions! Best Regards, Bryan Digital Communications Specialist
Answered by: Customer Service
Date published: 2023-03-29

Does the RP46463 replace a RP47201 cartridge?

Asked by: carl
Hi Carl, Thank you for your question about the Delta Faucet RP46463 Cartridge Assembly MultiChoice® Universal - 17 Series. We will be happy to assist you in finding this information as quickly as possible. These MulitChoice cartridges are included with different series trim kits. A 17 series trim kit includes an RP46463 cartridge. A Tempassure 17T series trim kit includes an RP47201 cartridge. These two cartridges would not fit the same faucet. Please reach out if you have any questions or need additional assistance. We appreciate your business and look forward to continuing to serve you! Best Regards, Bryan Digital Communications Specialist
Answered by: Customer Service
Date published: 2024-03-28

Difference between 46463 & 32104 cartridges

Asked by: Dsmith
Hi Dsmith, Thanks so much for contacting Delta Faucet Company about, RP46463! The RP32104 was manufactured for a 17 series pre-2006 model, the RP46463 was manufactured for a T17 trim kit post 2006. Please contact us directly if you have any questions or need additional assistance. Best Regards, Nicole Digital Communications Specialist
Answered by: Customer Service
Date published: 2023-04-03

Please tell me as exactly as possible what this means..."Requires inlet water temperature be set correctly. May require seasonal adjustments."

Asked by: AlanAZ
Hello Valued Customer, Thank you for contacting Delta Faucet Company! Most of our tub/shower cartridges are pressure balanced and have a maximum temperature of 120 degrees. If the temperature exceeds this amount, the cartridge may not work as it is designed. We appreciate your inquiry. Please reach out directly if you have further questions! Best Regards, Kyra Digital Communications Specialist
Answered by: Customer Service
Date published: 2024-10-24

Hello, I bought this cartridge to replace the one I have in a Shower Monitor T18230, but it is not identical. There is only one notch on one side (which is fine for the existing cartridge), instead of 2, so it doesn't fit. Is there a different one?

Asked by: Bianca
Hello Bianca, Thank you for contacting Delta Faucet Company! I am sorry this information was not readily available, and I am happy to help you! Our Delta Faucet Cartridge Assembly - MultiChoice® Universal - 17 Series MODEL#: RP46463 is the post-2006 cartridge with two tabs, the pre-2006 cartridge with one tab is RP32104. Please see the link below. https://www.deltafaucet.com/parts/product/RP32104.html Thank you for being a loyal Delta Faucet customer. Please contact us back with any further questions. Best Regards, Nicole
Answered by: Delta7
Date published: 2024-03-28

We have a delta shower. It's the series 17 cartridge. What is the warranty on the shower? Our shower just started leaking.

Asked by: DeWayne
Hi DeWayne, Thanks so much for contacting Delta Faucet Company! Our products have a Limited Lifetime Warranty that covers parts (other than electronic parts and batteries) and finishes of Delta® faucets purchased from authorized Delta sellers to the original consumer purchaser to be free from defects in material and workmanship for as long as the original consumer purchaser owns the home in which the faucet was first installed. I have included a link below for the warranty information. https://www.deltafaucet.com/service-parts/warranty It is possible that flushing the product could resolve this issue. To do this, turn off the water supplies, remove the cartridge, and turn the supplies back on for one minute. Please make sure that you are getting good flow through both the hot and cold sides while flushing. You can also shake the cartridge back and forth to make sure the back half of the cartridge rattles. This means that the pressure-balancing spool is moving freely, as it should. If you would like installation help, you may contact our residential warranty line directly at 800-345-3358 (prompt 2, then 4). We also have how-to videos on our website and on our YouTube channel. https://www.deltafaucet.com/service-parts/how-to-videos Please reach out with further questions! Best Regards, Kelley Digital Communications Specialist
Answered by: Customer Service
Date published: 2024-03-28

Will this cartridge (RP46463) fit Monitor 1800 series?

Asked by: Adi V
Hi Adi V, Thank you for contacting us at Delta Faucet! Yes, the RP46463 cartridge will be used for 1800 series trim kits installed after April of 2006. If it was installed prior to this date it will utilize the RP32104 cartridge. Please contact us directly if further assistance is needed at this time.   Best Regards, Tim Digital Communications Specialist
Answered by: Customer Service
Date published: 2024-03-28

When I bought this faucet I was told replacement parts were free.

Asked by: Llambert
Hi Llambert, Please accept our sincere apology for the inconvenience you are experiencing. We have reached out to you via email to further assist at this time. Best Regards, Tim Digital Communications Specialist
Answered by: Customer Service
Date published: 2024-10-29

For replacing a part of Delta 17, instead of ordering  RP46463 can I just get the adapter:   attaches to the valve body with a screw, O-rings on the back, and spring/seats on the front. I have a slow leak and  think the cartridge is fine.

Asked by: Kenno
Hi Kenno, Thank you for your question about the Delta Faucet RP46463 17 series cartridge. Yes, a slow leak is likely caused by wear to the rubber seats or seals. We recommend replacing the RP46073 adapter with the rubber parts behind the cartridge. The new adapter doesn't need a screw, but it is interchangeable with the older adapter. https://www.deltafaucet.com/parts/product/RP46073.html Please reach out with any additional questions! Best Regards, Bryan Digital Communications Specialist
Answered by: Delta
Date published: 2025-01-09

How do I get parts for my delta shower 1700 series warranted?

Asked by: scott
Hi Scott, thank you for your interest in the RP46463! We are happy to assist you! We have reached out to you directly via email in regard to this matter. Please contact us directly if you have any questions or need additional assistance. Best Regards, Themar Digital Communications Specialist
Answered by: Customer Service
Date published: 2023-03-20

This a new installation. I just installed RP46463 cartridge into R10000 rough valve body. What could be the reason for the cartridge not turning off the water flow? Water doesn't stop when I rotate the ON/OFF lever.

Asked by: ZorDelta
Hi ZorDelta, Thanks for your question regarding RP46463! I'm sorry you are experiencing a leak from your shower unit; however, I'm happy to assist you. I have included a link below from our Help Center to assist you further. https://support.deltafaucet.com/s/article/RP46463-Shower-Cartridges Please feel free to contact us with any questions or for further assistance. Best Regards, Emma Digital Communications Specialist
Answered by: Customer Service
Date published: 2024-03-13

Does this work for 17t/18t? Shower

Asked by: Whatksit
Hi Whatksit, Thank you for your question! A 17T / 18T faucet uses a thermostatic cartridge. RP47201 https://www.deltafaucet.com/parts/product/RP47201.html Please reach out if you have any additional questions! Best Regards, Bryan Digital Communications Specialist
Answered by: Customer Service
Date published: 2023-05-31

What is the replacement cartridge part number for DELTA T27859-SS STAINLESS TRINSIC 1 HOLE WALL MOUNT MONITOR 17 SERIES VALVE TRIM WITH 3 SETTING DIVERTER

Asked by: Kristine
Hi Kristine, Thank you for your question about the Delta Faucet model T27859. A replacement cartridge is part number RP46463. The included adapter behind the cartridge is RP46073. If there is a shower drip, the rubber parts of the adapter may be worn or damaged. Please reach out with any additional questions! Best Regards, Bryan Digital Communications Specialist
Answered by: Delta
Date published: 2025-08-12

I have a model T17078. Can the seal in the cartridge front of the cartridge be replaced. It is leaking out the front

Asked by: bob16
Hi bob16! Thank you for your question and we are happy to help. The RP4993 seats and springs can be replaced in the Delta T17078. With any further questions or concerns, please do not hesitate to reach out to us again. Best Regards, Carrie
Answered by: Customer Service
Date published: 2024-03-28

I have RP464663 Cartridge assy for multichoice universal 17 series. Being used in new shower, no tube, but the water flowing as if there is a tub. Is the plug so the cartridge will only support shower head ? thank you

Asked by: Bob1
Hi Valued Customer, Thank you for your question, please accept our sincere apology for the inconvenience you are experiencing. We will be happy to assist you in resolving this issue as quickly as possible. This will function a shower head only. Please feel free to contact us directly for technical information at 800-345-3358. We are available Monday through Friday from 8 a.m. to 8 p.m. and Saturdays from 9 a.m. to 6 p.m. Eastern Standard Time. Thank you for being a loyal Delta Faucet customer. Best Regards, Themar Digital Communications Specialist
Answered by: Themar
Date published: 2025-12-16

Do you warranty this part?

Asked by: Bill
Hi Bill, Thank you for your question! I am sorry this information was not readily available, and I am happy to help! All Delta Faucet products purchased from authorized sellers are covered by our Lifetime Limited Warranty. https://www.deltafaucet.com/warranty Please contact us directly if you have any questions or need additional assistance. We appreciate your business and look forward to continuing to serve you! Best Regards, Bryan Digital Communications Specialist
Answered by: Customer Service
Date published: 2024-03-28

I need the OFFICIAL Installation Instructions to the Delta RP46463 Cartridge. Why isn't that on the Delta Website?

Asked by: Joseph L
Hello Customer! Thank you for your question and we are happy to help. The official installation instructions come with your product and they are available online under your trim kit model numbers maintenance and installation sheet. With any further questions or concerns, please do not hesitate to reach out to us again. Best Regards, Carrie
Answered by: Carrie
Date published: 2025-09-12

What is required to remove the existing cartridge after I turn off the water and remove the parts in front of the cartridge? Does it turn clockwise or counter clockwise to unlock before it comes out?

Asked by: Mike
Hello Mike, Thank you for contacting Delta Faucet Company! I am sorry this information was not readily available, and I am happy to help you! Our Delta Faucet DELTA® Cartridge Assembly - MultiChoice® Universal - 17 Series MODEL#: RP46463 can be pulled straight out of the valve body. There is not a lock on the cartridge to remove it. You may need to wiggle it out a little due to mineral deposits. If you need to remove any mineral deposits around the part's you may clean them with a 50/50 solution of white vinegar and water. Thank you for being a loyal Delta customer. Please feel free to call, email, or message us on social if there is anything else you need. Best Regards, Themar Customer Service Representative
Answered by: Delta
Date published: 2024-03-28

How do I change the shower cartridge?

Asked by: BobH
Hi Valued Customer, Thank you for your question. Turn off water supplies. Remove the cover bonnet nut from the body. Insert adapter assembly into valve body. Make sure the adapter assembly is correctly positioned and is pressed all the way down inside body. Remove the retainer from the adapter. Rotate cartridge so the words “HOT SIDE” appear on the left. Insert cartridge assembly into valve body. Make sure the key on the cartridge is fully engaged with the slot in the brass body. Slide bonnet nut over the cartridge and thread onto the body. Hand tighten the bonnet securely. If you need further assistance, feel free to contact us directly. https://media.deltafaucet.com/MandI/102477%20Rev%20A.pdf Please feel free to contact us directly for technical or warranty information at 800-345-3358. We are available Monday through Friday from 8 a.m. to 8 p.m. and Saturdays from 9 a.m. to 6 p.m. Eastern Standard Time. Thank you for being a loyal Delta Faucet customer. Best Regards, Themar Digital Communications Specialist
Answered by: Themar
Date published: 2026-01-08
