Documents & Specs
Installation Information
Overall Height (in.) :
1-1/4
Valve Type:
NA
REVIEWS
Rated 1 out of
5
by
6 months from
We have had to replace this part after a year and now after 6 months!!! We like the faucet, but obviously this part is bad!
Date published: 2026-06-01
Rated 1 out of
5
by
Jamil from
Bad product
Horrible
expensive, leaks and needs to be changed every year
Date published: 2025-10-05
Q&A
My faucet cold water is dripping, started out of the blue. Do I need to replace the cartridge to stop the drip? It’s a 699-BL model that we bought August 2023.
Hello,
Please accept our sincere apology for the inconvenience you are experiencing. We have reached out to you via email to further assist at this time.
Best Regards,
Tim
Digital Communications Specialist
Date published: 2026-01-05
How do I replace a valve cartridge on a Delta one handle bathroom faucet
Hello,
Please accept our sincere apology for the inconvenience you are experiencing. We have reached out to you via email to further assist at this time.
Best Regards,
Tim
Digital Communications Specialist
Date published: 2025-01-10
My aunt has the delta pivotal kitchen faucet.or something similar... it has a slow leak on the cold side. 1) Would this cartridge fix this issue? 2) how do you get the button off of the set screw? 3)is this a part I can get at Lowe's Home Improvement?
Hi ChrisBrom,
Thank you for contacting Delta Faucet Company!
I see you have been assisted by one of our customer service representative. Please contact us directly if you have any questions or need additional assistance.
Best Regards,
Nicole
Digital Communications Specialist
Date published: 2024-03-28
is a DIY instruction sheet available for a 63053LF-GL kitchen faucet cartridge replacement
Hi Tom,
Thank you for your question about the Delta Faucet RP91902 cartridge.
Instructions for replacing this cartridge in the Brizo faucet are available here:
https://media.brizo.com/MandI/106350%20Rev%20B.pdf
Please reach out with any additional questions!
Best Regards,
Bryan
Digital Communications Specialist
Date published: 2025-02-11
I have the Broderick kitchen faucet Model#: 9190TL-DST. I have the cartridge RP91902 you sent. How do I install this cartridge?
Hello!
Thank you for contacting Delta Faucet Company!
To install the new cartridge on our 9190TL-DST, th4e water will need to be turned off, and the handle will need to be removed. The handle button can be removed with a fingertip, and the handle comes off with an allen wrench! After that the handle pulls off, and there is a bonnet nut holding the cartridge in. You can use an adjustable wrench to remove the bonnet nut, then note how the contact spring is installed.
We appreciate your inquiry. Please reach out directly if you have further questions!
Best Regards,
Kyra
Digital Communications Specialist
Date published: 2026-02-02
Drip from handle keeps occurring. does this need a cartridge assembly replacment?
Hello,
Please accept our sincere apology for the inconvenience you are experiencing. We have reached out to you via email to further assist at this time.
Best Regards,
Tim
Digital Communications Specialist
Date published: 2026-06-19
Hi, Is the flow restrictor built into this cartridge ( MODEL#: RP91902) and if so how do I change it. I have an ARA Model 567LF Faucet and cannot locate the restrictor in order to clean it. I almost have no water flow. Thanks
Hello Dad1,
Thank you for contacting Delta Faucet Company! I am sorry this information was not readily available for our Pivotal® Valve Cartridge In Chrome MODEL#: RP91902, and I am happy to help you!
The flow restrictor is located under the cartridge, please see the steps to find the restrictor and flush the unit.
Please shut water supplies off before starting this process. You will need Phillip's screwdriver and start by popping the cap off the front of the handle. Then you would remove your handle with the screwdriver. Please pull the handle off of the cartridge, you will then find the cap and bonnet nut. Both the cap and bonnet nut would be unthreaded from the faucet. The next part you should see is the cartridge, please grab and pull it out. Then using needle nose pillars, grab the brass insert and pull it out. Under the insert is the flow restrictor and this is where the blockage would be located, once cleaned follow the directions in reverse for reinstall.
Thank you for being a loyal Delta Faucet customer. We appreciate your business and look forward to continuing to serve you. Please contact us back with any further questions.
Best Regards,
Nicole
Date published: 2024-03-28
Is this valve considered a Euro-motion ceramic valve with InnoFlex® waterways? Or is the RP60114 the only Euro-motion ceramic valve with InnoFlex® waterways?
Hello Matthew,
Thank you for your question! We apologize that the information you are searching for was not readily available. We realize that can be very frustrating and I am happy to assist you! We thank you for being a loyal Delta Faucet customer.
The Delta Faucet part RP91902 Pivotal® Valve Cartridge In Chrome is a Euro-motion ceramic valve cartridge and is included with models that have included InnoFlex® Pex-C Supply Lines.
Please contact us back directly via email with any further questions.
Best Regards,
Skyler
Date published: 2024-03-28
