Monitor® 17 Series Valve Only Trim
Model#: T17038
Monitor® 17 Series Valve Only Trim
Monitor® 17 Series Valve Only Trim
Monitor® 17 Series Valve Only Trim
Monitor® 17 Series Valve Only Trim
Monitor® 17 Series Valve Only Trim
Model#: T17038
Finish: Chrome
List Price*: $159.15
  • Features a complete suite of coordinating products: Accessories, Faucets, and showers
  • Available in four finishes: chrome, Brilliance Stainless, Venetian Bronze, and Aged Pewter which extend the look throughout the bath.
  • Dual function pressure balance cartridge
  • Order MultiChoice(R) rough separately
  • Valve is not included, must purchase separately
  • Monitor Valve protects from rapid changes in hot or cold water
  • Backed by Delta Faucet’s Lifetime Limited Warranty
Special Features
ADA Compliant
ADA Compliant
Volume Control
Volume Control
Installation Information
Over All Height :
Connection Type :
Rated 5 out of 5 by from Simple design, easy control consistent performance Great choice with hot/cold mixing limits and easy on and off while keeping the previous temperature setting. Nice chrome finish that lasts ... replacing an identical nine year old control which had been damaged by previous homeowner.
Date published: 2021-02-13
Rated 5 out of 5 by from Nice shower valve I really like the independent flow and temperature controls on one yoke. This way you can set the temperature, and if you want to shut off the water for a short time and turn it back on the temp is right where you want it. Also allows for flow control at the set temp.
Date published: 2021-01-20
Rated 4 out of 5 by from Installation instructions Very good quality product. Wall installation instructions explaining how far out to extend it could be written to include different scenarios like installing with tile etc.
Date published: 2020-11-29
Rated 5 out of 5 by from Buy this one! The tradesman was quite pleased to see this was my shower valve choice, as was the over-seeing contractor. So I figured it was a good choice. I thoroughly researched the options and selected this one because I wanted something simple, with a good handle, a powerful valve, from a good company. Delta is wonderful! Very happy with my choice. It does not match the other hardware, but is nice and simple in design so that it complements pretty much anything.
Date published: 2020-11-15
Rated 5 out of 5 by from Beautiful addition to our bathtub! This is a beautiful addition to our bathtub. The design and color helped bring a more modern look to our bath. Installation was easy and straight forward and it works wonderfully. Simply turn the handle left or right to change temperature and it turns with ease. I would definitely recommend this to anyone hoping to update the look of their bath. A quick and easy remodel!
Date published: 2020-02-21
Rated 5 out of 5 by from very pretty beautiful in my bathroom, much better than the one i replaced. works smoothly and so far there are no leaks or drips and the seal is perfect. this is one of those things that really change the look of the room as well as save you money if you are replacing a defective unit.
Date published: 2020-02-15
Rated 5 out of 5 by from Beautiful! At first, I thought this was going to be really difficult to install, but it really wasn't. It was really very easy, and I don't have much experience with DIY plumbing. When it was all installed, it was a beautiful addition to my bathroom! It works smoothly, has no leaks or drips, and is aesthetically very pleasing.
Date published: 2020-02-14
Rated 4 out of 5 by from Good product. I installed this shower handle in my spare bathroom so it doesn’t get used very often. When it has been used it works just as well as I thought it would. The installation was fairly simple and the design is visually appealing. Overall a good product.
Date published: 2020-02-12
  • y_2021, m_2, d_26, h_17
  • bvseo_bulk, prod_bvrr, vn_bulk_3.0.14
  • cp_1, bvpage1
  • co_hasreviews, tv_0, tr_40
  • loc_en_US, sid_T17038, prod, sort_[SortEntry(order=SUBMISSION_TIME, direction=DESCENDING)]
  • clientName_deltafaucet
  • bvseo_sdk, dw_cartridge, 18.2.0, p_sdk_3.2.0
  • CLOUD, getReviews, 8ms
  • reviews, product

When I order T17038, what parts are included? The parts list I pulled up related to this # showed accessories as well as faucet parts and I couldn't distinguish. Thanks.

Asked by: Jim70
Hello Jim70, Thank you for your question. The Delta Lahara T17038 is a dual control Valve only trim kit. This kit included the escutcheon plate, screws, trim sleeve, cartridge assembly and volume and temperature handles. Best regards, Tanya
Answered by: Delta Faucet
Date published: 2018-06-12

What accessories go with this?

I am planning a tub to shower conversion and do not plan on having the tub spout at all. I have # 57014 showerhead and sliding bar, # 50560 elbow, and understand I need # R1000-UNBX valve. If I get T17038, is that everything I need for a new shower only setup? Thanks!
Asked by: mary
Thank you for your question. If you are using Delta Faucet model # 57014 as your main showerhead, then you have all the components you will need for a complete shower only set-up.
Answered by: Delta1
Date published: 2013-10-22

what is the differences between 17t series and 17 series?

does either cartridge need to be maintained?
Asked by: bj
Hi bj, Thank you for your question! Both series operate the same and do not require regular maintenance. The Monitor 17 series is pressure balanced. The TempAssure 17T series is thermostatic, which provides a more precise temperature control. The 17T series will also provide more flow from the valve if you are building a customer shower with multiple components. Best regards, Jon
Answered by: DeltaFaucet3
Date published: 2017-01-26

What is the diameter of this trim?

Asked by: sharon
Hi, Sharon! Thank you for your question. The Delta Monitor T17038 Valve Trim escutcheon plate measures 7 1/2" (191 mm) in diameter. Here is a link to the technical specifications sheet for further measurements for the trim kit: Best Regards, Rosanna
Answered by: Delta Faucet
Date published: 2020-04-08

Do I need to caulk around the edges of the trim against the tile?

Asked by: Derek
Hi, Derek! Thank you for your question. We do recommend to use a bit of silicon sealant to seal the trim of the Delta T17038 unit against the tile. Best Regards, Rosanna
Answered by: Delta Faucet
Date published: 2019-03-15

Why is the oring packaged in the same plastic bag with the bolts/hardware? I hope my trim does not leak once I install it because of a damaged oring.

Asked by: paprikaspiroska
Hi paprikaspiroska, Thank you for your question. The o-ring in the photo goes under the trim sleeve that covers up the valve body and helps hold the trim sleeve in place. The o-ring is not used to seal water from leaking. Thanks, Dave
Answered by: DeltaFaucet2
Date published: 2014-12-18

Will the T17038 trim kit work with a 1500 series valve?

Asked by: jmo6259
Hi, jmo6259! Thank you for your question. The Delta Monitor T17038 Trim Kit will fit the Delta 1500 Series Valve if the original escutcheon plate has the screw holes at the 1 & 7 o'clock position. The new cartridge, RP46463, that is included with the Monitor T17038 Trim Kit, will not fit the 1500 Series Valve. The original cartridge, RP32104, will need to be used. Please feel free to call, email, or message us on social if further assistance is needed. Best regards, Rosanna Phone: 1-800-345-3358 | Email: | Facebook/Twitter: @deltafaucet
Answered by: Delta Faucet
Date published: 2020-04-06

Will this work for a tub only installation? Do you have a kit with this trim kit and a non diverter tub spout?

Asked by: Larry
Hi, Larry! Thank you for your question. We do not make a trim kit with a non-diverter tub spout to match this Delta Lahara Monitor T17038 Valve Trim Kit, however, this trim kit will work as a tub only installation. Best Regards, Rosanna
Answered by: Delta Faucet
Date published: 2019-09-20
