Foundations®
Monitor® 13 Series Tub & Shower Trim in Stainless
Model#:
BT13410-SS
PRODUCT FEATURES
Monitor® pressure balance valve keeps water temperature within a safe ±3.6° F (± 2.0⁰ C), helping to protect you from sudden changes in hot or cold water pressure
- Spray settings: Full spray and Soft spray
- Full spray provides a steady, full-coverage spray perfect for every shower need, from rinsing shampoo from hair to relaxing tired muscles
- Pull-up tub spout diverts water from the tub spout to shower head
- Trim kit only, must order MultiChoice® Universal valve rough (R10000 series) separately to complete the unit
- Stem extension kit RP77991 can be ordered for an additional 1 3/4 inch wall thickness
- Back-to-back installation capability
- WaterSense® labeled shower heads use at least 20% less water than the industry standard without compromising performance
- ADA compliant
- Backed by Delta Faucet's Limited Lifetime Warranty
Special Information
California Prop 65 WARNING
CALIFORNIA PROP 65 WARNING
<b>WARNING: </b>Risk of cancer and reproductive harm from exposure to Lead. See www.P65Warnings.ca.gov.
For more information go to http://www.P65Warnings.ca.gov
Eco-Friendly
WaterSense® Labeled
Technology and Special Features
ADA Compliant
ADA Compliant
Some people, and some local codes, require fixtures that are compliant with the Americans with Disabilities Act. If someone may visit who has special needs, or if you believe future buyers might appreciate this feature, Delta offers a range of compliant fixtures.
Brilliance® Finish
Brilliance® Finish
Many Delta products are made with Brilliance® finishes, which resist abrasions and discolorations better than traditional brass or even chrome.
Water-Efficient
Water-Efficient
CalgreenCert Tooltip information here...
Monitor®
Monitor®
Delta Monitor® faucets feature pressure balance valves, which protect against sudden temperature or pressure changes to keep the water in the shower within a safe ±3.6° F.
Special Information
California Prop 65 WARNING
CALIFORNIA PROP 65 WARNING
<b>WARNING: </b>Risk of cancer and reproductive harm from exposure to Lead. See www.P65Warnings.ca.gov.
For more information go to http://www.P65Warnings.ca.gov
Documents & Specs
Product Support, Repair Parts & Technical Specifications
Resources
Installation Information
Flow Rate :
1.75 gpm @ 80 psi, 6.6 L/min @ 552 kPa
Overall Height (in.) :
11-31/32
Valve Type:
Single-function pressure balance cartridge
INSTALLATION SUPPORT
Need help with installation? Find local Delta® installers. Get Quotes. Read reviews.
REVIEWS
Rated 1 out of
5
by
Jeff from
Changes not documented in instructions
They changed the mounting of the tube spigot but they didn't update the instructions to reflect the new type. Its a piece of garbage!!
Date published: 2025-07-07
Rated 3 out of
5
by
JCR from
-
tub spout does not tighten completely.
Date published: 2023-08-18
Rated 3 out of
5
by
Tnm242520 from
Handle falls off
We bought this set up for our bathrooms. Everything was easy to install and hook up aside for the knob to turn water on and off. It falls off after tightening down
Date published: 2022-05-31
Rated 5 out of
5
by
Lisa from
Delta Foundations
[This review was collected as part of a promotion.] Great product! Delta makes a reliable product!
Date published: 2019-11-18
Rated 5 out of
5
by
Chuck83 from
Easy to install
[This review was collected as part of a promotion.] I was flipping a house. Valve looked good, installed new trim & cartridge. Looked & worked like a new faucet at half the cost & labor.
Date published: 2019-11-18
Rated 5 out of
5
by
Karrigan from
Easy to install
This is a nice set to upgrade my bathroom. Sleek design adds to the overall look of my tub/shower. Was easy to install, provides great water coverage and genuinely gives my bathroom a much needed upgrade. Easy to clean and looks great!
Date published: 2019-10-22
Rated 5 out of
5
by
Ss69 from
Perfect
I got this shower assembly and switched my existing one out and it's perfect! It was very easy ro switch out. It came with clear, concise instructions for installation. Now that it's up it looks and feels absolutely perfect for my shower.
Date published: 2019-10-22
Rated 5 out of
5
by
AlexQ from
Nice Delta Faucet
Delta Faucet's design is beautiful, traditional and elegant. It is made of excellent quality materials. It is easy to install. It is very easy to change water temperature. My bathtub is very pretty after installing my new Delta Faucet.
Date published: 2019-10-22
Q&A
I have a BT13410-ss and am looking for a large escutcheon plate that would match. The plate needs to be a minimum of 10"X 6.5" Any recommendations?
Hi, Sandy!
Thank you for your question. We do have a renovation plate that matches the Brilliance Stainless Steel Finish on the Delta Monitor BT13410-SS Tub and Shower Trim Kit. The part number is RP29827SS. Here is a link to the part:
https://www.deltafaucet.com/parts-product-detail?modelNumber=RP29827SS
Best Regards, Rosanna
Date published: 2024-03-28
How can this be upgraded?
We are having a new home built and the builder (Brookfield) is using this model (Foundations Monitor 13) in the bathrooms. I want to upgrade everything. Shower head, spigot, and handle, to something nicer. What Delta shower packages can I upgrade to without having to rip out the wall?
Thanks... Mike
Hi, Mike D!
Thank you for your question. Any new trim kit that starts with T13, T14, T17, and T17T will work with your existing valve body inside of your wall. Here is a link to the shower units:
https://www.deltafaucet.com/bathroom/showering/tub-and-shower-faucets
Best Regards,
Rosanna
Date published: 2024-03-28
Are there any parts of this that are non-metallic? If so, please identify.
Hi Candy,
Thank you for your question! The shower head, tub spout, and cartridge are non-metallic. All other parts will be metal.
Best regards,
Jon
Date published: 2024-03-28
I have a Scald Guard shower/bath valve that was installed in 1993. I do not know what the model was. I am looking to update the trim only.
Is it safe to assume the 1300/1400 model line trim would fit?
Thank you for your question. If your faucet turns on by turning the handle to the right or left, you have a 1300/1400 series faucet. You can use any 1300/1400 trim but you will need to keep your old cartridge. The cartridge that comes with the new trim will not work with your older valve.
If you turn on your faucet by pushing up and then turning to the right or left, you have a 600 series faucet. The 1300/1400 trim will not work with the 600 series.
Date published: 2024-03-28
Can I use this trim with the #58470 in2ition h2okinetic shower/handshower?
Hi SCmom,
Thank you for your question. You sure can! Any Delta shower head will work with this trim.
Best regards,
Jon
Date published: 2024-03-28
I have the delta tub and shower B114900. I am trying to install the tub spout onto a 1/2" copper pipe that is 4" from my wall. It will not push flush to the wall. There is a 3/4" gap. Do I need to cut the copper pipe to 3 1/4"?
Dbrinton,
Thank you for your question. For a slip-on installation, the pipe should extend 1-1/2" to 2-3/4” from the finished wall. Threaded installations require a 3-7/8" to 4” pipe.
Best regards, Jon
Date published: 2024-03-28
Do all shower/bath faucet kits come with the cartridge to insert in the Delta Multichoice rough-in?
Hi, Chad!
Thank you for your question. All of our Delta Shower Bath Trim Kits do include the needed valve cartridge assembly to install with the trim and valve body.
Best Regards, Rosanna
Date published: 2024-03-28
I have a 1400 series pre 2006 shower valve. Would this trim kit work ?
Hi Seth,
Thank you for your question!
Yes, this trim kit will install onto your existing valve. However, you must use the existing RP19804 cartridge assembly.
Please reach out with further questions!
Best Regards,
Tim
Digital Communications Specialist
Date published: 2024-10-16
PART LIST
PART LIST
View Product
![Image-RP4993]()
Delta®
Delta® Seats & Springs (2 ea)
List Price:
$10.10
Online Price:
$8.08
Free Ground Shipping All Orders $49+
RP4993
4.70
100
View Product
![Image-Master-RP50879]()
Dryden®
Dryden® Trim Sleeve - Tub & Shower
List Price:
$33.80
-
$76.80
Free Ground Shipping All Orders $49+
RP50879
View Product
![Image-Master-RP64722]()
Foundations®
Foundations® Tub Spout - Non-Diverter
List Price:
$75.60
-
$111.30
Free Ground Shipping All Orders $49+
RP64722
View Product
![Image-RP46074]()
![Secondary Image-RP46074]()
Delta®
Delta® Cartridge Assembly - MultiChoice® Universal - 13 / 14 Series
List Price:
$118.35
Online Price:
$94.68
Free Ground Shipping All Orders $49+
RP46074
2.24
105
View Product
![Image-RP14414]()
Delta®
Delta® O-Rings (2) - 13 / 14 Series
List Price:
$4.60
Online Price:
$3.68
Free Ground Shipping All Orders $49+
RP14414
5.00
2
View Product
![Image-Master-RP6023]()
Delta®
Delta® Shower Arm
List Price:
$43.65
-
$109.60
Free Ground Shipping All Orders $49+
RP6023
View Product
![Image-RP23336]()
Delta®
Delta® O-Ring - Large - All Monitor® Series
List Price:
$7.70
Online Price:
$6.16
Free Ground Shipping All Orders $49+
RP23336
5.00
5
View Product
![Image-RP29569]()
Delta®
Delta® Spacer
List Price:
$4.90
Online Price:
$3.92
Free Ground Shipping All Orders $49+
RP29569
5.00
1
View Product
![Image-Master-RP6025]()
Delta®
Delta® Flange - Shower
List Price:
$23.10
-
$36.90
Free Ground Shipping All Orders $49+
RP6025
